Specification:
Model: YZC-131A
Dimensions: 75x12.7x8mm/2.95 x 0.51 x 0.31"(L x W x H)
Range:3 kg
Rated Load: 3 kg
Rated output: 1.0 ± 0.1mV / V
Nonlinear: ± 0.05% F.S
Hysteresis: 0.0% F.S
Repeatability: 0.05% F.S
Creep (5 minutes): 0.05% F.S
Temperature Effect on Output: 0.003% F.S /°C
Zero output: ± 0.2 mV / V
Input impedance: 1050 ± 10% Ω
Output impedance: 1000 ± 10% Ω
Insulation resistance: ≥2000 MΩ
Operating temperature range: -21 ~ 40°C
Recommended for: kitchen scales
Weight:21g
Kuongshun Electronic, one of the international well-known manufacturers and suppliers of weighing load cell sensor 3kg for electronic kitchen scale yzc-131 with wires which is situated in China, now has quality products for sale. We are equipped with a group of professional and experienced workers, as well as advanced equipment. You can rest assured to buy discount and low price weighing load cell sensor 3kg for electronic kitchen scale yzc-131 with wires made in China from us and check the pricelist with us.
